      TriBand Antenna HPA65R-KE4A




  PI HPA65RKE4AA front isometric PI HPA65RKE4AA back isometric
  • Four foot (1.2 m), TriBand, six port antenna with a 65° azimuth beamwidth covering 694-960 MHz and 1695-2690 MHz frequencies
  • Four wide high band ports covering 1695-2690 MHz and two wide low band ports covering 694-960 MHz in a single antenna
  • New enclosure with <12” (305 mm) width, narrowest enclosure in the industry
  • Full Spectrum Compliance 694-960 MHZ / 1695-2690 MHz
  • LTE Optimized FBR and SPR performance, providing for an efficient use of valuable radio capacity
  • LTE Optimized Boresight and Sector XPD and USL performance, essential for LTE Performance
  • Exceeds minimum PIM performance requirements
  • Ordering options for 7/16 DIN connector or the new 4.3-10 connector, which is 40% smaller than traditional 7/16 DIN connector
  • Ordering options for 2 or 3 field replaceable, integrated AISG 2.0 compliant Remote Electrical Tilt (RET) controllers

MBK-02   MBK-02 Mounting Kit
BSA-RET200   Remote Electrical Tilt System (RET)
HPA-CBK-AG-RRU   TriBand antenna with 3 RET to RRU AISG cable kit
HPA-CBK-RA-AG-RRU   TriBand antenna with 3 RET to RRU AISG right angle cable kit
QPA-CBK-AG-RRU   TriBand antenna with 2 RET to RRU AISG cable kit
QPA-CBK-RA-AG-RRU   TriBand antenna with 2 RET to RRU AISG right angle cable kit
SCU-AISG-P   Portable AISG 2.0 Site Control Unit
Configuration File
