      Broadband Pentaplexer Combiner 5PO-6736-xxx




  PI 5PO6736ST2 V1.0 190222
  • Combines 600/700, 850/900, PCS (1850-1995), AWS (1695-2200) and WCS/BRS (2305-2690), which includes AWS 1-3 Extended
  • High power 60 W per port with low insertion loss
  • Low intermodulation with typical isolation of >50 dB per band
  • DC/AISG pass option, Smart Bias-T with pass through on any input port or integrated AISG modem and port
  • Outdoor model available in both single and twin configurations
  • Also available in a 1U 19" rack mount, see model 5PR-6736-xxx
  • High reliability of >500K Hours MTBF and multi-strike lightning protection

Overview





Communication Components, Inc. Broadband Pentaplexer Combiner combines 600/700, 850/900, PCS, AWS and WCS/2600 band Basestation Tx/Rx signals onto a common port. Specifically intended for use in feeder line limited sites or multi-band high power DAS systems, the CCI Outdoor Pentaplexer model 5PO-0636-xxx facilitates the addition of new technologies like 5G and new spectrum including 600 MHz and "AWS 1-3 Extended" to existing sites while providing a low insertion loss and a high degree of isolation between systems. The cost and complexity of upgrading a Macro or DAS site is 6 reduced.
The CCI Broadband Pentaplexer Combiner provides full band performance for each band with low insertion loss, low Intermodulation, and high power handling. Excellent return loss delivers the best match to the DAS system and base station, saving precious transmit power.This unit is an outdoor version available in a single or twin configuration and 19 inch rackmout version is also available in a single or twin configuration, see model number 5PR-6736-xxx. Both rackmount and outdoor units are fully weather rated.



Technical Description:

The Broadband Pentaplexer Combiner consists of a multiple filters to combine (or divide) full band 600/700, 850/900, PCS, AWS, and WCS/2600 Band signals. This unit can be used as either a splitter or combiner to aggregate multiple bands on a common line. RF ports are available with 7-16 or 4.3-10 connectors. The filters have been designed to minimize insertion loss while maximizing isolation. Particular attention has been given to the intermodulation performance of the Broadband Pentaplexer to minimize any passive intermodulation products from occurring. This Outdoor Version can be pole or wall mounted and all connectors are fully IP68 rated and the unit body is rated for IP67. The mounting kit is included as an accessory.

Electrical Specification

RF Parameters Ports Frequency(MHz) Specification
Return Loss Common 617 - 798 18 dB min., 20 dB typ.
824 - 960 18 dB min., 20 dB typ.
1850 - 1995 18 dB min., 20 dB typ.
1695 - 1780 18 dB min., 20 dB typ.
2110 - 2200 18 dB min., 20 dB typ.
2305 - 2690 18 dB min., 20 dB typ.
600/700 617 - 798 18 dB min., 20 dB Typ.
850/900 824 - 960 18 dB min., 20 dB typ.
PCS 1850 - 1995 18 dB min., 20 dB typ.
AWS 1695 - 1780 18 dB min., 20 dB typ.
2110 - 2200 18 dB min., 20 dB typ.
WCS/2600 2305 - 2690 18 dB min., 20 dB typ.
Insertion Loss COM to 600/700 617 - 798 0.35 dB typ., 0.55 dB max.
COM to 850/900 824 - 960 0.35 dB typ., 0.65 dB max.
COM to PCS 1850 - 1995 0.35 dB typ., 0.40 dB max.
COM to AWS 1695 - 1780 0.35 dB typ., 0.40 dB max.
2110 - 2200 0.35 dB typ., 0.40 dB max.
COM to WCS/2600 2305 - 2690 0.35 dB typ., 0.55 dB max.
Isolation COM to 600/700 824 - 960 50 dB min.
1850 - 1995 50 dB min.
1695 - 1780 50 dB min.
2110 - 2200 50 dB min.
2305 - 2690 50 dB min.
COM to 850/900 617 - 798 50 dB min.
1850 - 1995 50 dB min.
1695 - 1780 50 dB min.
2110 - 2200 50 dB min.
2305 - 2690 50 dB min.
COM to PCS 617 - 798 50 dB min.
824 - 960 50 dB min.
1695 - 1780 50 dB min.
2110 - 2200 50 dB min.
2305 - 2690 50 dB min.
COM to AWS 617 - 798 50 dB min.
824 - 960 50 dB min.
1850 - 1995 50 dB min.
2305 - 2690 50 dB min.
COM to WCS/2600 617 - 798 50 dB min.
824 - 960 50 dB min.
1850 - 1995 50 dB min.
1695 - 1780 50 dB min.
2110- 2180 50 dB min.
2180 - 2200 40 dB min.

General Characteristics
Impedance 50 ohms
Continuous Average Power 100 W max.
Peak Envelope Power 2 kW max.
Intermodulation Performance COM port <-117 dBm (-160 dBc) typical (2 × +43 dBm tones) all bands

Environmental Specification

Operating Temperature -40˚C to +65˚C (Outdoor)
Ingress Protection IP68(Connectors), I67 (Unit Body)
Relative Humidity 0 - 99% (Outdoor)
MTBF >500,000 hours
Lightning Protection 8/20us, ±10KA max, 10 strikes each, IEC61000-4-5

Mechanical Specification

Modularity Single Twin
Connectors 6 × 7-16 DIN female long neck or 6 × 4.3-10 - per Pentaplexer
Dimensions (body only) 9.21 × 17.72 × 1.73 in.
(234.0 × 450.0 × 44.0 mm)
9.21 × 18.19 × 3.70 in.
(234.0 × 462.0 × 94.0 mm)
Dimensions (with connectors & bracket) 12.72 × 17.72 × 2.36 in.
(323.0 × 450.0 × 60.0 mm)
12.72 × 18.19 × 4.33 in.
(323.0 × 462.0 × 110.0 mm)
Weight 18.75 lbs (8.5 kg) 37.65 lbs (17.1 kg)
Frontal Wind Load 431.1 N @150km/hour 431.1 N @150km/hour
Lateraal Wind Load 35.0 N @150km/hour 74.7 N @150km/hour
Mounting Pole/Wall mount



  OD 5PO6736SS1 V1.1 190220
  Outdoor Single Broadband Pentaplexer Outline Drawing
   OD 5PO0636MT1 V1.0 190215
  Outdoor Twin Broadband Pentaplexer with AISG Modem Outline Drawing

Block Diagram

  BD 5PO0636Sxx V1.0 190214
  Outdoor Broadband Pentaplexer with Smart Bias-T Block Diagram
   BD 5PO0636Mxx V1.0 190214
  Outdoor Broadband Pentaplexer with AISG Modem Block Diagram

Accessories

Wall Mount Kit   Included

Parts & Accessories

5PO-6736-x-S1 Outdoor Single Broadband Pentaplexer with 7-16 DIN connectors
5PO-6736-x-S2 Outdoor Single Broadband Pentaplexer with 4.3-10 connectors
5PO-6736-x-T1 Outdoor Twin Broadband Pentaplexer with 7-16 DIN connectors
5PO-6736-x-T2 Outdoor Twin Broadband Pentaplexer with 4.3-10 connectors

Option (-x) Description
-S Smart Bias-T, DC/AISG Pass through on any port
-0 No DC/AISG Pass through
-1 DC/AISG Pass through 600/700 Band to COMMON, DC Block on all other input ports
-2 DC/AISG Pass through 850/900 Band to COMMON, DC Block on all other input ports
-3 DC/AISG Pass through PCS to COMMON, DC Block on all other input ports
-4 DC/AISG Pass through AWS to COMMON, DC Block on all other input ports
-5 DC/AISG Pass through WCS/BRS to COMMON, DC Block on all other input ports
-M AISG Modem with AISG output port

Certifications

Safety EN 60950-1, UL 60950-1
Emission EN 55022
Immunity EN 55024
Environmental IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-5, IEC 60068-2-6, IEC-60068-2-11, IEC 60068-2-14, IEC 60068-2-18, IEC 60068-2-27, IEC 60068-2-29, IEC 60068-02-30, IEC 60068-2-52, IEC 60068-2-64, IEC61000-4-5, GR-63-CORE 4.3.1, EN 60529 IP67, IP68

Certifications

Antenna Interface Standards Group (AISG), Federal Communication Commission (FCC) Part 15 Class B, CE, CSA US, ISO 9001
