      Ten Port Multi-Band Antenna DPA65R-BU6A




  PI DPA65RBU6A front iso PI DPA65RBU6A Rear iso
  • Six foot (1.8 m) multiband, 10 port antenna with a 65° azimuth beamwidth covering 698-896 MHz and 1695-2360 MHz frequencies
  • Full Spectrum Compliance for WCS, AWS3 and upcoming Band 14 Operations
  • LTE Optimized FBR and SPR performance, providing for an efficient use of valuable radio capacity
  • LTE Optimized Boresight and Sector XPD and USL performance, essential for LTE Performance
  • Exceeds minimum PIM performance requirements
  • Equipped with new 4.3-10 connector, which is 40% smaller than traditional 7/16 DIN connector
  • Ordering options for External RET Controllers (Type 1) or Internally Integrated RET Controllers (Type 17)
MBK-01   MBK-01 Mounting Kit
BSA-RET200   Remote Electrical Tilt System (RET)
BSA-RET400   Remote Electrical Tilt System (RET)(Type 17)
DPA-CBK-AG-RRU   AISG Cable set for three RET antenna
DPA-CBK-RA-AG-RRU   AISG Right Angle Cable set for three RET Antenna
SCU-AISG-P   Portable AISG 2.0 Site Control Unit
Configuration File
