Communication Components, Inc. 700W AC/DC Small Cell Power Supply provides a Universal AC Power alternative to power most –48 VDC Remote Radio Heads and other auxiliary outdoor equipment operating on –48VDC. The Small Cell Power Supply is a highly efficient convection cooled power source and as such does not require any internal or external fans for normal operation. The heatsink is integrated into the Power Supply housing and provides adequate convection cooling in outdoor ambient environments. The Power Supply enclosure and input and output connectors are completely weather sealed making it suitable for outdoor deployment in all environmental conditions. High reliability and high efficiency make the 700W AC/DC Small Cell Power Supply an ideal solution for both indoor and outdoor AC powered applications.

The 700W Universal AC to –48 VDC Small Cell Power Supply provides a -54.5 VDC Nominal output at a load of up to 14 ADC continuously. The input voltage can vary from 85 to 240VAC (47-63 Hz) while maintaining continuous operation under all rated load conditions.
The Small Cell Power Supply is power factor corrected with a minimum power factor rating of 0.95. The power supply utilizes a highly efficient power converter circuit achieving typical efficiency in excess of 88% at 70% rated load. Noise and ripple are kept below 4 V peak-to-peak under all load conditions.
Overcurrent and overvoltage protection is built into the Small Cell Power Supply to prevent damage to the power supply with an automatic recovery feature. The overcurrent circuit will trigger between 105% and 140% of rated load and the overvoltage will trigger between 60-69 VDC. Both will automatically recover when the OC and OV conditions return to normal.
The Power Supply is fully weather sealed and the housing is IP67 rated, making it suitable for all outdoor environmental conditions. The output connection IP55 rated 12 AWG, 2 wire outdoor connection with an exposed, open end cable for custom termination.
