| 4×4 Wideband Hybrid Combiner |
HYO-77-4xx | |||
 |
|
| Input Connectors | 7-16 DIN or 4.3-10 female × 4 (Port 1 - 4) |
| Output Conncetors | 7-16 DIN or 4.3-10 female × 4 (Port 5 - 8) |
| Dimensions (body)(H×W×D) | 350 × 100 × 55.4 mm (13.78 × 3.94 × 2.18 in.) |
| Dimensions (incl. brackets)(H×W×D) | 350 × 230 × 65 mm (13.78 × 9.06 × 2.56 in.) |
| Weight with brackets | 4.44 Kg (9.78 lbs) |
| Mounting | Pole/Wall mounting bracket |
 |
|
| 4 × 4 Hybrid Combiner Outline Drawing |
|
|
 | FREQUENCY BAND | |
 | 617-698 MHz (600 Band) |
| 698-798 MHz (700 Band) |
| 790-862 MHz (LTE 800) |
| 806-869 MHz (SMR 800) |
| 816-869 MHz (SMR 800ABC) |
| 824-894 MHz (Cellular) |
| 880-960 MHz (GSM 900) |
| 1427-1518 MHz (IMT 1400) |
| 1710-1880 MHz (DCS) |
| 1695-1780/2110-2180 MHz (AWS) |
| 1850-1995 MHz (PCS) |
| 1920-2170 MHz (IMT 2100) |
| 2305-2360 MHz (WCS) |
| 2300-2400 MHz (TDD) |
| 2496-2690 MHz (BRS) |
| 2570-2620 MHz (TDD) |
| 2500-2570/2620-2690 MHz (FDD) |
 |
|||
