CCI’s PDO-68 series of Power Dividers deliver high power performance at 100 Watts, while covering a wide frequency band 698 to 3800 MHz. Each model provides low PIM values with very low insertion loss and excellent return loss performance. The units are offered in a range of dividing values which is very useful for optimizing RF power distribution which is often required for distributed antenna systems (DAS).

The extremely wide frequency range allows use with multiband and broadband antennas and DAS systems, and the high power handling makes them ideal for use with wireless base stations. These units are constructed with a weatherproof aluminum IP65 rated housing and with IP65 immersion rated connectors suited to long-life outdoor use. The power dividers can be wall mounted with the included bracket and the RF ports can be configured with either 4.3-10 type connectors.

CCI filter and combiner products are designed and produced to ISO 9001 certification standards for reliability and quality at our state-of-the-art engineering and manufacturing facilities.
