0.5 Meter AISG Cable | AISGC-M-F-20 | |||
|
|
|
CCI’s 19.7 in (0.5) meter AISG Male to Female Jumper cable is AISG 2.0 compliant and backward compatible with AISG 1.1. CCI AISG cables are equipped with Standard 8 pin circular connectors per IEC 60130-9 and optionally available with DB15 connectors This AISG cable has IP67 outdoor ingress protection, when properly mated. The cable jacket is matte black polyurethane and is fire retardent per UL 1581 VW-1. |
Cables per kit | 1 |
Connectors | 2 x 8 pin IEC 60130-9 Straight male/ Straight female |
Tightening torque | Hand tighten only ≈ 1.84 ft-lbs (2.5 Nm) |
Construction | Shielded (Tinned Copper Braid) |
Braid coverage | 85% |
Jacket Material | Matte Polyurethane (Black) |
Conductors | 1 twisted pair - 22 AWG 3 conductors - 18 AWG |
Cable Diameter | 0.307 in (7.8 mm) |
Length (L in diagram) | 19.7 in (500 mm) |
Minimum bend radius | 3.15 in (80 mm) |
AISG-Female to AISG-Male Jumper Cable |
|
